DISPLAY
- Active viewing area: 4.3″ (109 mm) VGA LCD TFT (640 x 480) Landscape Display
- High-visibility backlit LCD
OPERATING SYSTEM AND SOFTWARE
- Microsoft® Windows Embedded Handheld 6.5.3
- Multiple OS languages (English, French, Spanish, German, Portuguese)
- Adobe Reader® LE
PROCESSOR AND MEMORY
- 1.0 GHz ARM Cortex A8 i.MX53 processor
- 512 MB RAM
MEMORY AND DATA STORAGE
- 8 GB flash storage
- User-accessible micro SD/SDHC slot
PORTS
- COM1, RS-232C 9-pin D connector with5VDC power output on pin 9 software-enabled
- USB host (Full A), USB client (Micro B)
- 12, 24VDC input, 10-36V unregulated
- 3.5 mm audio jack, supports speaker/ microphone or stereo output (pin detect)
- IO docking ports for charging, USB port connector protector
- USB port connector protector
TOUCHSCREEN
- Projected capacitive touch interface
- Chemically-strengthened glass
- Scratch-resistant screen
KEYBOARD
- Full numeric and QWERTY keypad
- Adjustable backlit keys
|
BATTERY
- Intelligent Li-Ion battery 3.7VDC @ 10600 mAh, 38.7 Whr
- Operates 20+ hours on a single
- Charges in 2 to 4 hours
- Battery easily changeable in field
- Optimized for excellent performance in cold temperatures
PHYSICAL
- Size, Standard models: 5.4” w x 10.2” l x 1.6” d (138 mm x 256 mm x 40 mm)
- Weight: 2 lbs (908 g), with battery
- Durable hardened plastic in a shear-proof and shock-resistant design
- Strong chemical resistance
- Comfortable, wide hand strap
- Easy-to-grip, impact-absorbing bumpers
WIRELESS CONNECTIVITY OPTIONS
- Bluetooth® wireless technology, 2.1 +EDR, Class 1.5, line-of-sight range up to 1500 feet (450 meters) when paired with Class 1 Bluetooth device
- Wi-Fi® 802.11b/g/n with extended range
- 3.75G modem(3G Models) – Pentaband Worldwide Frequencies: HSPA+/UMTS: 800/850/900/1800/1900/2100MHz
- Data communication interface
ENVIRONMENTAL
- IP68 waterproof and dustproof
- Operating temperature: –22 F to 140 F (–30 C to 60 C)
- Storage temperature: –22 F to 158 F (–30 C to 70 C)
- Note: Bluetooth® wireless technology is rated to –4 F (–20 C)
- Shockproof: multiple drops from 5′ (1.5 m) onto concrete
- MIL-STD-810G test procedures: Method 500.5 Low Pressure (Altitude); Method 501.5 High Temperature; Method 502.5 Low Temperature; Method 503.5 Temperature Shock; Method 506.5 Rain; Method 507.5 Humidity; Method 510.5 Sand and Dust; Method 512.5 Immersion; Method 514.6 Vibration; Method 516.6 Shock
|
CAMERA (GEO MODEL)
- 5 MP resolution w/ autofocus & LED illuminator + video capture
- Juniper Geotagging™: embed & emboss photo with date, time, and GPS position
GNSS (GEO MODEL)
- High-sensitivity GPS/GLONASS/ SBAS receiver
- User settings for enhanced performance under canopy
- Accuracy: SBAS 2 meters; autonomous 5 meters
- NMEA and BINR output
- 32 channel all-in-view tracking
- JSNav GNSS positioning and navigation app
CERTIFICATIONS & STANDARDS
- FCC Class B
- CE Marking (applicable EMC, R&TTE, and
- LVD directives)
- Industry Canada
- EN60950 Safety
STANDARD ACCESSORIES
- 10600 mAh battery
- AC wall charger with international plug kit
- Micro USB client sync cable
- Quick Start Guide
- Adjustable hand strap
- Screwdriver
- Stylus with tether
- 2-year Mfr. warranty (extendable)
|
