| Angle Measurements (Hz, V) |
| Accuracy (ISO 17123-3) |
5” (1.5 mgon), 2” (0.6 mgon), 1" (0.3086 mgon) |
| Method |
Absolute, continuous, diametrical |
| Compensation |
Quadruple axis |
| Display resolution |
0.1” (0.1 mgon) |
|
| Distance Measurements |
| Prism (range, accuracy) |
3,500 m (12,000 ft), 1 mm +
1.5 ppm |
| Prism, long-range (range, accuracy) |
10,000 m (33,000 ft), 5 mm +
2 ppm |
| Non-prism (range, accuracy) |
1,000 m (3,300 ft), 2 mm +
2 ppm |
| Laser dot size (non-prism) |
7 mm x 10 mm at 30 m, 8 mm x 20 mm at 50 m |
|
| Motorization |
| Rotating speed |
45° (50 gon)/s |
|
| Aiming |
| Range (round / 360° prism) |
1,000 / 800 m (3,300 / 2,600 ft) |
| Accuracy (ISO 17123-3) |
1” (0.3 mgon) |
|
| Tracking |
| Range (round / 360° prism) |
800 / 600 m (2,600 / 2,000 ft) |
| Speed |
90km/h at 100 m |
|
| Searching |
| Range |
300 m (1,000 ft) |
| Typical search time |
5 – 10 sec |
| Search area |
Default Hz: 360°, V: 36°, definable search window |
|
NavLight
|
| Working range |
5 – 150 m (15 to 500 ft) |
| Positioning accuracy |
5 cm at 150 m (2” at 330 ft) |
|
Keyboard and Display
|
| Display |
Full VGA color LCD, touch screen |
| Keyboard |
Two full alphanumeric; 35 keys: illumination (2nd optional) |
|
Data Storage and Interface
|
| Memory / storage |
1GB internal / Removable SD card and USB stick |
| Interface |
Bluetooth® wireless technology, RS232, ZRT80 radio modem |
|
| Weight / Environmental Conditions |
| Weight |
5.5 kg (total station fully equipped) |
| Operating temperature |
-20° to +50°C (-4° to +122°F) |
| Protection against water and dust |
IP55, 95 % humidity non-condensing |
|
Power Management
|
| Battery |
Removable Li-Ion 7.4V, 4.4 Ah |
| Operating time |
8 h |
|
